阀的额定压力是通过调节弹簧力实现，当P口压力达到设定压力后，阀被打开，

P到T开始溢流;反方向，从T到P可以很低的压力打开。该阀反应灵敏、内泄漏小
The rated pressure of the valve is achieved by adjusting the spring force

and allows free flow from P to T while the pressure at Preaches the valve

setting; In the opposite direction free flow from T to P at very low pressure.

The valve offers quick response and low internal leakage.

1.额定压力(Rated pressure):160bar

2.额定流量(Rated flow):30L/min

3.开启率(Cracking Rate)≥90%

4.闭合率(Closing Rate)≥85%

5.补油开启压力(Oil Makeup Cracking Pressure):1.6bar

6.内泄漏 (internal Leakage)≤10ml/min at 165bar

7.油液清洁度(Cleaning Code):20/18/15(NAS9)

8.工作温度(Temperature range):-20~+100℃

9.每转压力变化(Pressure change Per Turn):76bar

10.安装扭矩(Installation Torque):35~40Nm

11.锁紧扭矩(Nut Tightening Torque):23~28Nm
